Mon, Jul 27, 2015

Another way to capture LAN packets with pcap4j container

Another way to capture LAN packets with pcap4j container

2 days ago, I posted an article How to capture packets on a local network with Pcap4J container.

Today, I was reading Docker Docs and found another way to do it. I’m writing about it here.


–net option for docker run

When we start a docker container we use docker run command. It accepts some options. --net is one of them, which is to set a network mode for a container. Network modes --net takes are bridge, none, container:<name|id>, and host. The bridge is the default mode where containers connect to the virtual Ethernet bridge docker0.

What I use in this article is host mode. If it’s specified containers use the host network stack, which means Pcap4J on a container with the host mode can see network interfaces on its host and sniff network traffic via them directly.

This sounds easy. And more, according to the Docker Docs, the host mode gives significantly better networking performance than the bridge mode. But instead, host is insecure. (See Docker Docs - Mode: host for the details.)

What I did

In the same environment with 2 days ago, I did the followings:

  1. Start a Pcap4J container with the network mode set to host

      [root@localhost ~]# docker run --name pcap4j-hostnet --net=host kaitoy/pcap4j:latest


    That’s it.

    The above command create a container named pcap4j-hostnet from the image kaitoy/pcap4j:latest and execute /bin/sh /usr/local/src/pcap4j/bin/capture.sh eth0 false in the container. The capture.sh starts packet capturing on eth0 using Pcap4J. This eth0 is the interface of the docker host mashine because the network mode is set to host.

    What a easy way.
